Hybrid Artificial Intelligence and Metaheuristics for Smart City TRafci Management Problem Video Chapters: 00:00 Introduction 00:40 Smart Cities 01:14 Traditional Methods for Traffic Management 02:12 Hybrid Approach AI and Metaheuristics 02:47 STEPS for Hybrid Traffic Management System 08:40 Advantages of Smart Traffic Management System 09:33 Conclusion
A bio-inspired algorithm which mimic the huddling behavior of Emperor Penguin.
Video Chapters:
Introduction: 00:00
What is emperor penguin optimization: 00:23
Emperor Penguin: 00:58
Emperor Penguin huddle: 01:50
Emperor Penguin Optimizer Flowchart: 03:19
Generate Emperor Penguin huddle boundary: 04:34
Calculate Temperature around huddle: 06:18
Calculate Distance between Emperor Penguins: 07:45
Relocate Effective Mover: 09:45
Emperor Penguin Optimization Steps: 10:52
Conclusion: 12:38
Emperor Penguin Optimizer is a Novel Bio-Inspired Metaheuristic Algorithm which is inspired by the huddling behavior of Emperor Penguin. Penguins are Aquatic Flightless Birds. Penguins spends their 50% life on the land and 50% life in the water. Penguin largest species is known as Emperor Penguin. Both male and female emperor penguins are similar in size. Emperor penguin is the only species which use huddle for their survival in Antarcticwinter. Huddle is used as a defense against cold to survive through though Antarctic winter. Huddling is used to conserve energy and increase temperature during winter. Without Huddle they lose energy and freeze.
Four Important phases to describehuddling behavior of Emperor penguins in Emperor Penguin Optimization Algorithm:
Step 01: Generate and determine the huddle boundary for Emperor Penguins.
Step 02: Calculate temperature around the Huddle.
Step 03: Determine the distance between the Emperor Penguins.
Step 04: Find out Effective Mover and Relocate.
Emperor Penguin Optimizer Pseudocode:Step 01: Initialize the Emperor Penguins population randomly in the search space.
Step 02: Initialize all important initial parameters such as Maximum Iterations, Temperature, A, C.
Step 03: Calculate fitness values for all search agents.
Step 04: Determine the huddle boundary for Emperor penguins using:
Step 05: Calculate temperature profile (T') around the huddle using:
Step 06: Compute distance between the emperor penguins using:
Step 07: Update the position of emperor penguins.
Step 08: If any emperor penguin goes beyond the huddle boundary improve its position.
Step 09: Calculate fitness values for each search agent and update new optimal solution position.
Step 10: If stopping criteria met Stop else Goto Step 05.
Step 11: Return Best Emperor Penguins/ Optimal Solutions.
PARTICLE SWARM OPTIMIZATION ALGORITHM NUMERICAL EXAMPLE PSO is a computational method that Optimizes a problem. It is a Population-based stochastic search algorithm. PSO is inspired by the Social Behavior of Birds flocking. n Particle Swarm Optimization the solution of the problem is represented using Particles. [Flocking birds are replaced with particles for algorithm simplicity]. Objective Function is used for the performance evaluation for each particle / agent in the current population. PSO solved problems by having a Population (called Swarms) of Candidate Solutions (Particles). Local and global optimal solutions are used to update particle position in each iteration. Particle Swarm Optimization (PSO) Algorithm step-by-step explanation with Numerical Example and source code implementation. - PART 2 [Example 2] 1.) Initialize Population [Current Iteration (t) = 0] Population Size = 4; 𝑥𝑖 : (i = 1,2,3,4) and (t = 0) 𝑥1 =1.3; 𝑥2=4.3; 𝑥3=0.4; 𝑥4=−1.2 2.) Fitness Function used:
Cuckoo Search Algorithm - Metaheuristic Optimization Algorithm What is Cuckoo Search Algorithm? Cuckoo Search Algorithm is a Meta-Heuristic Algorithm. Cuckoo Search Algorithm is inspired by some Cuckoo species laying their eggs in the nest of other species of birds. In this algorithm, we have 2 bird Species. 1.) Cuckoo birds 2.) Host Birds (Other Species) What if Host Bird discovered cuckoo eggs? Cuckoo eggs can be found by Host Bird. Host bird discovers cuckoos egg with Probability of discovery of alien eggs. If Host Bird Discovered Cuckoo Bird Eggs. The host bird can throw the egg away. Abandon the nest and build a completely new nest. Mathematically, Each egg represent a solution and it is stored in the host bird nest. In this algorithm Artificial Cuckoo Birds are used. Artificial Cuckoo can lay one egg at a time. We will replace New and better solutions with less fit solutions. It means eggs that are more similar to host bird has opportunity to develop in the new generation a
Particle Swarm Optimization (PSO) is a p opulation-based stochastic search algorithm. PSO is inspired by the Social Behavior of Birds flocking. PSO is a computational method that Optimizes a problem. PSO searches for Optima by updating generations. It is popular is an intelligent metaheuristic algorithm. In Particle Swarm Optimization the solution of the problem is represented using Particles. [Flocking birds are replaced with particles for algorithm simplicity]. Objective Function is used for the performance evaluation for each particle / agent in the current population. After a number of iterations agents / particles will find out optimal solution in the search space. Q. What is PSO? A. PSO is a computational method that Optimizes a problem. Q. How PSO will optimize? A. By Improving a Candidate Solution. Q. How PSO Solve Problems? A. PSO solved problems by having a Population (called Swarms) of Candidate Solutions (Particles). Local and global optimal solutions are used to upda
Particle swarm optimization (PSO) What is meant by PSO? PSO is a computational method that Optimizes a problem. It is a Population-based stochastic search algorithm. PSO is inspired by the Social Behavior of Birds flocking. n Particle Swarm Optimization the solution of the problem is represented using Particles. [Flocking birds are replaced with particles for algorithm simplicity]. Objective Function is used for the performance evaluation for each particle / agent in the current population. PSO solved problems by having a Population (called Swarms) of Candidate Solutions (Particles). Local and global optimal solutions are used to update particle position in each iteration. How PSO will optimize? By Improving a Candidate Solution. How PSO Solve Problems? PSO solved problems by having a Population (called Swarms) of Candidate Solutions (Particles). The population of Candidate Solutions (i.e., Particles). What is Search Space in PSO? It is the range in which the algorithm computes the op
There are about 1000 species of Bats. Bat Algorithm is based on the echolocation behavior of Micro Bats with varying pulse rates of emission and loudness. All bats use echolocation to sense distance and background barriers. Microbats are small to medium-sized flying mammals. Micro Bats used a Sonar that is known as Echolocation to detect their prey. Bats fly randomly with the velocity at the position with a fixed frequency and loudness for prey. Q. Whats is Frequency? A. Frequency is the number of waves that pass a fixed point in unit time. Wavelength is the minimum distance between two nearest particles which are in the same phase. Here, Sound waves are used by microbats to detect prey. Q. What is Position? A. A place where something or someone is located. Q. What is Velocity? A. Speed of something in a given direction. Q. What is loudness. A. Loudness refers to how soft or loud sound seems to listeners. Q. What is pulse rate? A. Wave or vibration. In th
Grey Wolf Optimization Algorithm (GWO) Grey Wolf Optimization Grey Wolf Optimization Algorithm is a metaheuristic proposed by Mirjaliali Mohammad and Lewis, 2014. Grey Wolf Optimizer is inspired by the social hierarchy and the hunting technique of Grey Wolves. What is Metaheuristic? Metaheuristic means a High-level problem-independent algorithmic framework (develop optimization algorithms). Metaheuristic algorithms find the best solution out of all possible solutions of optimization. Who are the Grey Wolves? Wolf (Animal): Wolf Lived in a highly organized pack. Also known as Gray wolf or Grey Wolf, is a large canine. Wolf Speed is 50-60 km/h. Their Lifespan is 6-8 years (in the wild). Scientific Name: Canis Lupus. Family: Canidae (Biological family of dog-like carnivorans). Grey Wolves lived in a highly organized pack. The average pack size ranges from 5-12. 4 different ranks of wolves in a pack: Alpha Wolf, Beta Wolf, Delta Wolf, and Omega Wolf. How Grey Wolf Optimization Algorithm
Local Binary Pattern Introduction to Local Binary Pattern (LBP) Q. What is Digital Image? A. Digital images are collections of pixels or numbers ( range from 0 to 255). Q. What is Pixel? A. Pixel is the smallest element of any digital image. Pixel can be categorized as Dark Pixel and Bright Pixel. Dark pixels contain low pixel values and bright pixels contain high pixel values. Q. Explain Local Binary Pattern (LBP)? A. Local binary pattern is a popular technique used for image processing. We can use the local binary pattern for face detection and face recognition. Q. What is LBP Operator? A. LBP operator is an image operator. We can transform images into arrays using the LBP operator. Q. How LBP values are computed? A. LBP works in 3x3 (it contain a 9-pixel value ). Local binary pattern looks at nine pixels at a time. Using each 3x3 window in the digital image, we can extract an LBP code. Q. How to Obtain LBP operator value? A. LBP operator values can be obtained by using the simp
Grey Wolf Optimization Algorithm Numerical Example Grey Wolf Optimization Algorithm Steps 1.) Initialize Grey Wolf Population. 2.) Initialize a, A, and C. 3.) Calculate the fitness of each search agent. 4.) 𝑿_𝜶 = best search agent 5.) 𝑿_𝜷 = second-best search agent 6.) 𝑿_𝜹 = third best search agent. 7.) while (t<Max number of iteration) 8.) For each search agent update the position of the current search agent by the above equations end for 9.) update a, A, and C 10.) Calculate the fitness of all search agents. 11.) update 𝑿_𝜶, 𝑿_𝜷, 𝑿_𝜹 12.) t = t+1 end while 13.) return 𝑿_𝜶 Grey Wolf Optimization Algorithm Numerical Example STEP 1. Initialize the Grey wolf Population [Initial Position for each Search Agent] 𝒙_(𝒊 ) (i = 1,2,3,…n) n = 6 // Number of Search Agents [ -100, 100] // Range Initial Wolf Position 3.2228 4.1553 -3.8197 4.2330 1.3554 -4.1212 STEP 2. Calculate Fitness for Each Search Agent. Objective Function: F6(x) = su
Whale Optimization Algorithm Code Implementation Whale Optimization Algorithm Code Files function obj_fun(test_fun) switch test_fun case 'F1' x = -100:2:100; y=x; case 'F2' x = -10:2:10; y=x; end end function [LB,UB,D,FitFun]=test_fun_info(C) switch C case 'F1' FitFun = @F1; LB = -100; UB = 100; D = 30; case 'F2' FitFun = @F2; LB = -10; UB = 10; D = 30; end % F1 Test Function function r = F1(x) r = sum(x.^2); end % F2 Test Function function r = F2(x) r = sum(abs(x))+prod(abs(x)); end end function Position = initialize(Pop_Size,D,UB,LB) SS_Bounds = size(UB,2); if SS_Bounds == 1 Position = rand(Pop_Size,D).*(UB-LB)+LB; end if SS_Bounds>1 for i = 1:D UB_i = UB(i); LB_i = LB(i); Position(:,i) = rand(Pop_Size,1).*(UB_i-LB_i)+LB_i; end end end function [Best_Val,Best_Pos,Convergence_Curve]=WOA(
